Hi All,

I was looking at deploying the GREN Map using the HELM chart and I seem to be running into a couple of issues.

1. The openldap bitnami image not being available on docker when I try the preparation steps. (GitHub - grenmap/GREN-Helm-Deployment-Example: How to run a GREN map DB node on Kubernetes * GitHubhttps://github.com/grenmap/GREN-Helm-Deployment-Example) 2. Redis version no longer available in docker repository (I think) 3. Grenmap-django image pull issue (may be an authentication issue)

I was able to build the openldap image and get the IdP container running before moving on to building the HELM chart. However, I seem to have issues with redis version no longer available and an issue getting the grenmap-django image.

I was wondering if anyone has come across this issue before or if there is anything obvious that I may be missing when trying to build this (this is my first time building this using the HELM chart but I think I ran into similar issues with images when testing previously).

Any help would be greatly appreciated?

cd demo-config ./configure.sh

/GREN-Helm-Deployment-Example/demo-config/GREN-Map-DB-Node$ vim docker-compose.idp.yml openldap: image: bitnami/openldap:latest environment: - LDAP_PORT_NUMBER=1389 - LDAP_ADMIN_PASSWORD=${LDAPPWD} - LDAP_ROOT=dc=example,dc=org - LDAP_CUSTOM_SCHEMA_FILE=/bitnami/openldap/custom/schema/openLdapEduperson.ldif - LDAP_CUSTOM_LDIF_DIR=/bitnami/openldap/custom/ldif volumes: - ./openldap/container_files:/bitnami/openldap/custom

I was getting this error.

Error response from daemon: failed to resolve reference "docker.io/bitnami/openldap:latest": docker.io/bitnami/openldap:latest: not found

I was able to build this container following this site (bitnami/openldap - Docker Imagehttps://hub.docker.com/r/bitnami/openldap) And I was able to move on to the build the HELM chart but I'm now seeing an error when trying to pull some other images:

GREN-Helm-Deployment-Example$ kubectl get pod NAME READY STATUS RESTARTS AGE app-d7785d7b8-tgxtj 0/1 ImagePullBackOff 0 25m grenmap-db-5b67d57b8c-qkhvw 1/1 Running 0 25m grenmap-taskrunner-69fcdc489-qw6n4 0/1 ImagePullBackOff 0 25m grenmap-websp-55d5bb94fb-95rmh 0/1 Init:ImagePullBackOff 0 25m redis-7b79db7567-xxkk8 0/1 ImagePullBackOff 0 25m

One issue seems to the redis version not available

Normal Pulling 22m (x5 over 26m) kubelet Pulling image "bitnami/redis:7.0" Warning Failed 22m (x5 over 26m) kubelet Failed to pull image "bitnami/redis:7.0": Error response from daemon: manifest for bitnami/redis:7.0 not found: manifest unknown: manifest unknown Warning Failed 22m (x5 over 26m) kubelet Error: ErrImagePull Normal BackOff 50s (x106 over 26m) kubelet Back-off pulling image "bitnami/redis:7.0" Warning Failed 50s (x106 over 26m) kubelet Error: ImagePullBackOff

And another issue seems to be with the django image, with maybe an authentication error?

Warning Failed 26m (x5 over 29m) kubelet Failed to pull image "grenmap-django:latest": Error response from daemon: pull access denied for grenmap-django, repository does not exist or may require 'docker login': denied: requested access to the resource is denied Warning Failed 26m (x5 over 29m) kubelet Error: ErrImagePull Normal BackOff 4m42s (x104 over 29m) kubelet Back-off pulling image "grenmap-django:latest" Warning Failed 4m15s (x106 over 29m) kubelet Error: ImagePullBackOff
